Bottom Bracket Model Shimano SM-BB72-41B Bottom Bracket Type PressFit 86.5x41 Bottom Bracket Width 86mm
Brake Disc Mount Center Lock
Brakes Shimano 105 BR-R7170
Cable Routing Integrated Cable Routing System
Material Type Advanced Carbon Tech Dual 30
Cassette Ratio 11-34T
Cassette Shimano CS-R7101
Chain Shimano CN-M7100
Chainring 50-34T
Crank Shimano 105 FC-R7100
Downtube Mount Option No
Fender mount option No
Fork Material Advanced Carbon Tech Dual 30
Fork Max Tyre Clearance 32mm
Fork Mount Option No
Fork tube Tapered (1-1/8" - 1.5")
Front Brake Shimano RT-CL800 160mm
Front derailleur Shimano 105 FD-R7100
Handlebar Type Airflow II
Handlebar Flare 4
Handlebar Material Carbon
Headset Lower Bearing IS52/28.6 | IS52/40 45°
Headset Type Token A-Box
Headset Upper Bearing IS52/28.6 | IS52/40 45"
Max. Tyre Clearance 32mm
Rear Brake Shimano RT-CL800 140mm
Rear Derailleur Shimano 105 RD-R7100
Rim Type Hooked (Crochet)
BTSSaddleSize 244x148mm
Seatpost material Carbon
Shift levers Shimano 105 ST-R7120
Stem Drop -5,5
Stem material Carbon
BTSStuurlintType Isaac Momentum
Thru Bolt Front 12x100mm
Thru Bolt Rear 12x142mm
Toptube Mount Option No
BTS TyreType Goodyear Eagle 700x30C
Saddle Type Surface Powerbox
Colour name Mineral White
Crank arm length (mm) 170
Finish Glossy
Frame weight 1.150 gram (L)
Handlebar road drop (mm) 121
Handlebar road reach (mm) 53
Handlebar width (mm) 420
Color White
Model BOSON
Net weight (g) 8150
Rim height (mm) 30
Rim Inner Width (mm) 22
Rim outer width (mm) 26
Seat post setback (mm) 25
Speed ratio 2x12
Stem length (mm) 100
Tubeless Yes
Wheelset Type DT Swiss E1800
